제품 상세 정보:
|
| 소프웨어: | 오닉스 | 기계 작동 전력: | 7kw |
|---|---|---|---|
| 자동등급: | 오토매틱 | 적합한 직물 유형: | 폴리에스테르 & 면 |
| 미디어 처리: | 롤 롤 + 자동 피드 + 자동 롤업 | 잉크 종류: | 승화 잉크, 안료 잉크 |
| 전원공급장치: | AC380, 50/60HZ | 색상 및 페이지: | 여러 가지 빛깔의 |
| 용법: | 실내 및 실외 광고 분야 | 호환 OS: | Windows 7 & Windows 10 |
| Parameter | Specification |
|---|---|
| Model type | CSR3200 |
| Print head | 4 pieces i3200A1 |
| Ink | Sublimation ink, pigment ink |
| Number of nozzles | (400 nozzles*8lines)*4head |
| Color | Dual CMYK |
| Print head high | 1.5mm/6mm (adjustable) |
| Ink supply mode | Continuous ink supply |
| Max materials width | 3300mm |
| Max printing width | 3200mm |
| Roll outer diameter | 3 inch |
| Maximum weight for roll material | 100kg |
| Interface | USB2.0 |
| RAM | 128M |
| Printer Power | AC380V ,50/60HZ |
| Power | Heater 3KW Printer 4KW |
| Temperature | 30-32℃ |
| Humidity | 40-60%(Non-condensing) |
| Resolution (dpi) | Speed |
|---|---|
| 720*1200dpi (4 pass) | 78m²/h |
| 720*2400dpi (8 pass) | 52m²/h |
| 360*1200dpi (2 pass) | 136m²/h |
